Aquarium Metric Tank Connectors & Bulkheads

Click/Tap for further info or to buy

Part No: 0208

20mm PVC-U TANK CONNECTOR

Description: 20mm Tank Connector. Hole required 22-28mm. The stem end of the fitting is 20mm so you will need a 20mm joint socket to connect your pipe to it. The threaded end is ½ inch BSP male thread and if you wish to connect to this end you will need a fitting with a ½ inch female thread. Example: A threaded connector. With the locking nut at the end of the thread the maximum panel thickness is 15mm. This fitting is best installed with the thread inside.
In Stock
Price: £2.99

Part No: 0209

25mm PVC-U TANK CONNECTOR

Description: 25mm Tank Connector. Hole required 27-30mm. The stem end of the fitting is 25mm so you will need a 25mm joint socket to connect your pipe to it. The threaded end is ¾ inch BSP male thread and if you wish to connect to this end you will need a fitting with a ¾ inch female thread. Example: A threaded connector. With the locking nut at the end of the thread the maximum panel thickness is 12mm. This fitting is best installed with the thread inside
In Stock
Price: £3.25

Part No: 0210

32mm PVC-U TANK CONNECTOR

Description: 32mm Tank Connector. Hole required 34-39mm. The stem end of the fitting is 32mm so you will need a 32mm joint socket to connect your pipe to it. The threaded end is 1 inch BSP male thread and if you wish to connect to this end you will need a fitting with a 1 inch female thread. Example: A threaded connector. With the locking nut at the end of the thread the maximum panel thickness is 20mm. This fitting is best installed with the thread inside
In Stock
Price: £7.36

Part No: 0211

40mm PVC-U TANK CONNECTOR

Description: 40mm Tank Connector. Hole required 43-47mm. The stem end of the fitting is 40mm so you will need a 40mm joint socket to connect your pipe to it. The threaded end is 1¼ inch BSP male thread and if you wish to connect to this end you will need a fitting with a 1¼ inch female thread. Example: A threaded connector. With the locking nut at the end of the thread the maximum panel thickness is 30mm. This fitting is best installed with the thread inside
Item Available in 5 day(s). Place on back order.
Price: £13.25

Part No: 0212

50mm PVC-U TANK CONNECTOR

Description: 50mm Tank Connector. Hole required 49-55mm. The stem end of the fitting is 50mm so you will need a 50mm joint socket to connect your pipe to it. The threaded end is 1½ inch BSP male thread and if you wish to connect to this end you will need a fitting with a 1½ inch female thread. Example: A threaded connector. With the locking nut at the end of the thread the maximum panel thickness is 30mm. This fitting is best installed with the thread inside
In Stock
Price: £14.70

Part No: 0265

20mm PVC-U SLIP TANK CONNECTOR

Description: 20mm slip tank connector. Required hole size 27 to 30mm. Tank connector fits into the hole and then the pipe passes through the middle. Pipe is held in place by seal and lock nut. Pipe can be removed at anytime. Thread is ¾ inch BSP male and if you wish to attach to this you will require a fitting containing a ¾ inch BSP female thread. Example: Blanking cap.
In Stock
Price: £6.99

Part No: 0266

25mm PVC-U SLIP TANK CONNECTOR

Description: 25mm slip tank connector. Required hole size 34 to 39mm. Tank connector fits into the hole and then the pipe passes through the middle. Pipe is held in place by seal and lock nut. Pipe can be removed at anytime. Thread is 1 inch BSP male and if you wish to attach to this you will require a fitting containing a 1 inch BSP female thread. Example: Blanking cap.
In Stock
Price: £8.50

Part No: 0267

32mm PVC-U SLIP TANK CONNECTOR

Description: 32mm slip tank connector. Required hole size 42 to 49mm. Tank connector fits into the hole and then the pipe passes through the middle. Pipe is held in place by seal and lock nut. Pipe can be removed at anytime. Thread is 1¼ inch BSP male and if you wish to attach to this you will require a fitting containing a 1¼ inch BSP female thread. Example: Blanking cap.
In Stock
Price: £9.99

Part No: 0268

40mm PVC-U SLIP TANK CONNECTOR

Description: 40mm slip tank connector. Required hole size 54 to 60mm. Tank connector fits into the hole and then the pipe passes through the middle. Pipe is held in place by seal and lock nut. Pipe can be removed at anytime. Thread is 1¾ inch BSP male and if you wish to attach to this you will require a fitting containing a 1¾ inch BSP female thread. Example: Blanking cap.
In Stock
Price: £11.20

Part No: 0269

50mm PVC-U SLIP TANK CONNECTOR

Description: 25mm slip tank connector. Required hole size 61 to 69mm. Tank connector fits into the hole and then the pipe passes through the middle. Pipe is held in place by seal and lock nut. Pipe can be removed at anytime. Thread is 2 inch BSP male and if you wish to attach to this you will require a fitting containing a 2 inch BSP female thread. Example: Blanking cap.
In Stock
Price: £17.50

Part No: 0270

20/25mm PVC-U BONDED TANK CONNECTOR

Description: 20/25mm bonded tank connector. 20mm pipe can be bonded to the inside of both sides of this fitting. The stem side of the fitting also has an external measurement of 25mm therefore you can also connect 25mm pipe to the stem side by using a 25mm joint socket. The thread on the fitting is a male 3/4inch BSP Thread. If you wish to connect to the thread then you require a fitting with a 3/4inch BSP female socket. Required hole size is 27mm to 30mm. This is a VDL branded product.
In Stock
Price: £10.85

Part No: 0271

25/32mm PVC-U BONDED TANK CONNECTOR

Description: 25/32mm bonded tank connector. 25mm pipe can be bonded to the inside of both sides of this fitting. The stem side of the fitting also has an external measurement of 32mm therefore you can also connect 32mm pipe to the stem side by using a 32mm joint socket. The thread on the fitting is a male 1inch BSP Thread. If you wish to connect to the thread then you require a fitting with a 1inch BSP female socket. Required hole size 34mm to 39mm. This is a VDL branded product.
In Stock
Price: £11.35

Part No: 0272

32/40mm PVC-U BONDED TANK CONNECTOR

Description: 32/40mm bonded tank connector. 32mm pipe can be bonded to the inside of both sides of this fitting. The stem side of the fitting also has an external measurement of 40mm therefore you can also connect 40mm pipe to the stem side by using a 40mm joint socket. The thread on the fitting is a male 1¼inch BSP Thread. Required hole size 42mm to 49mm. This is a VDL branded product.
In Stock
Price: £12.99

Part No: 0273

40/50mm PVC-U BONDED TANK CONNECTOR

Description: 40/50mm bonded tank connector. 40mm pipe can be bonded to the inside of both sides of this fitting. The stem side of the fitting also has an external measurement of 50mm therefore you can also connect 50mm pipe to the stem side by using a 50mm joint socket. Required hole size 54mm to 60mm. This is a VDL branded product.
In Stock
Price: £14.50

Part No: 0274

50/63mm PVC-U BONDED TANK CONNECTOR

Description: 50/63mm bonded tank connector. 50mm pipe can be bonded to the inside of both sides of this fitting. The stem side of the fitting also has an external measurement of 63mm therefore you can also connect 63mm pipe to the stem side by using a 63mm joint socket. The thread on the fitting is a male 2inch BSP Thread. If you wish to connect to the thread then you require a fitting with a 2inch BSP female socket. Required hole size 63mm to 69mm. This is a VDL branded product.
In Stock
Price: £18.54
